SKU: THR-DMD-T781-NOR7E
MPN: DMD-NOR7E
Thork DMD Nor7e Navigation Tablet 7"

DMD Nor7e Adventure Navigation Tablet T781

A rugged 7" motorcycle navigation tablet built for ADV and group riding, combining flagship T880X performance with LoRa-enabled offline communication and expanded accessory connectivity.

Be among the first riders in the world to receive the DMD NOR7E, the most anticipated 7" navigation device to date.

Features:

• Same core hardware as the T880X with a powerful CPU, 8GB RAM, 128GB internal storage, dual-band GPS, 5G support, dual SIM plus eSIM capability, and an SD card slot for expanded storage.
• Integrated LoRa technology with SMA antenna connector and included antenna allows offline location sharing and group ride tracking without cellular coverage.
• Advanced Control & Inputs: Front-facing physical buttons for zoom and screen touch toggle, plus four top-mounted user-configurable buttons for custom functions while riding.
• Expanded M9 Accessory Support: Waterproof M9 power connector with remote controller support, plus a dedicated M9 accessories port capable of CAN, OBD, controllers, USB data, and custom cable solutions—supporting two USB accessories simultaneously.
• Rider-Optimized Display & Sensors: 7" 1920×1080 LTPS display rated at 2200 nits with polarized filter, hard coating, and thick glass for excellent visibility; includes barometric pressure and temperature sensors for environmental data.

Additional Details:

• No pogo pins
• No cameras
• Battery life up to approximately 3 hours
• Includes metal mounting holder with integrated vibration dampening

Dimensions & Weight:

• Device size: approx. 7.5 in × 4.3 in
• Device thickness: approx. 0.5 in
• Full assembly depth (device + holder): approx. 1.6 in
• Device weight: under 1.1 lb
• Device + holder weight: approx. 1.3 lb

Mounting Guide

For Motorcycles with 1/2" GPS Cross Bar (12mm):

• Use the DMD AMPS Base (with included spacers). This keeps the device mounted as close to the bar as possible for a low-profile look. Make sure there is enough clearance between the device and your windshield.
• If windshield clearance is tight (as with models like the BMW GS and Yamaha Ténéré 700), we recommend using a 12mm extension bracket, such as: short 12mm bracket with AMPS base or long 12mm bracket with AMPS base.

The motorcycles listed below are confirmed to have a 12mm GPS crossbar from the factory. The Yamaha Ténéré 700 is also recommended to use the DMD Dash Stabilizer for YAMAHA T7 (MY19-22) or DMD Dash Stabilizer for YAMAHA T7 (all versions from MY23 on).

For Motorcycles with 1 1/8" Handlebars (28mm):

• Use our shortest 28mm handlebar AMPS bracket (for 28mm handlebar only).
• For a closer viewing position, use our 22-28mm handlebar long bracket (for 22 and 28mm handlebars) with the short 12mm bracket with AMPS base.
• For flexible positioning and a secure hold, use our Adjustable Handlebar Clamp Mount.
• For more weather protection and adjustability, use our DMD Handlebar Mount Tower.

The motorcycles listed below are confirmed to have a 1 1/8" handlebar (28mm) from the factory.

For the KTM 790/890 ADV (2019-2022) / KTM 390 ADV (2020-2023) / Husqvarna Norden 901 (2022-2023):

Use our specific mount and AMPS converter.

For the KTM 790/890 (2023-):

Use our specific mount + if you need to push the device forward, we also recommend adding a spacer or the Super AMPS Converter.

For the Ducati DesertX:

Use our DMD Tower for Ducati DesertX.

For the BMW R1200GS (2008-2013):

Use our GPS mount for 17 mm tube.

For the Honda Africa Twin (2020-):

Use our GPS Mounting Bracket and short 12mm bracket with AMPS base.

For Universal Application:

Use our Adjustable Handlebar Clamp Mount.

For Motorcycles with 7/8" Handlebars (22mm):

• Use our 22mm GPS Mount.
• For a closer viewing position, use our 22-28mm handlebar long bracket (for 22 and 28mm handlebars) with the short 12mm bracket with AMPS base.
• For more weather protection and adjustability, use our DMD Handlebar Mount Tower.

The motorcycles listed below are confirmed to have a 7/8" handlebar (22mm) from the factory.
